ELECTRICAL DATA
– Nominal power 6.90 W
– Nominal voltage 220…240 V
– Equiv. Claimed conventional lamp power 80 W
– Max. lamp no. in case of circuit break. 10 A (B) 59
– Max. lamp no. in case of circuit break. 16 A (B) 97
– Operating frequency 50… 60 Hz
– Power factor λ > 0.50

PHOTOMETRIC DATA
– Luminous intensity [PIM] 1439 cd
– Nominal luminous flux 525 lm
– Nominal luminous flux 575 lm
– Main.fact. lumen at the end of the nominal service life 0.70
– Light colour (designation) Cool white
– Colour temperature 4000 K
– Luminous flux 525 lm
– Colour rendering index Ra ≥80
– Colour matching standard deviation ≤6 sdcm
– Nominal colour temperature 4000 K
– Colour rendering index Ra ≥80
– Nominal useful luminous flux 90 ° 575 lm
– Nominal useful luminous flux 90 ° 575 lm
– Luminous intensity nominal peak 1164 cd

LIGHT TECHNICAL DATA
– Beam angle 36 °
– Warm-up time (60%) <0.50 s
– Start time <0.5 s
– Nominal beam angle 36 °
– Nominal beam angle (half peak value) 36.00 °

DIMENSIONS AND WEIGHTS
– Total length 55.0 mm
– Diameter 51.0 mm
– External bulb PAR51
– Length 55.0 mm
– Maximum diameter 51.0 mm

TEMPERATURES AND OPERATING CONDITIONS
– Ambient temperature range -20…+40 °C
– Maximum temperature at test point tc 104 °C

LIFETIME
– Nominal lamp life 15000 h
– Nominal lamp life 15000 h
– Number of switching cycles 100000

ADDITIONAL PRODUCT DATA
– Base (standard designation) GU10
– Mercury content 0.0 mg
– Mercury-free Yes
– Show WEEE pictogram Yes

CAPACITIES
– Dimmable No

CERTIFICATES AND STANDARDS
– Energy efficiency class A +
– Energy consumption 7 kWh / 1000h

COUNTRY-SPECIFIC CATEGORISATIONS
– ILCOS DRPAR-6.9 / 840-220-240-GU10-50 / 36
– Purchase reference LPPAR168036 6.9
