Logistics Data

– Radium Code 43019063
– Description RL-PAR16 80 840/WFL
– EAN 10 (unit) 4008597190636
– Customs Tariff Number 85395000
– Transport Unit (pieces) 10
– EAN 40 (carton) 4008597490637
– Gross Carton Weight in kg 0.545
– Box Length in m 0.26
– Carton Width in m 0.11
– Carton Height in m0.07
– ETIM Class EC001959
– ETIM Class Designation LED Lamp

Electrical Parameters

– Nominal Power 6.9 watts
– Field Lamp Power rated power 6.9 W
– weighted energy consumption per 1,000 hours 6.9 kilowatt-hours
– Power factor 0.58
– rated voltage 220-240 volts
– voltage type AC
– rated current (mA) 51 milliamperes
– max. no. of Lps with 16A circuit breaker (B) with ballast (BE, BC without capacitor) / mains 97
– max. no. Lps with 10A circuit breaker (B) with ballast (BE, BC without capacitor) / mains 59

Lighting parameters

– Lamp luminous flux in rated field 575 lumens
– Luminous flux in 90° mains 575 lumens
– Luminous intensity 1439 candela
– Beam angle 36 degrees
– Luminous efficacy 83.33 lumens/watt
– Color temperature 4000 kelvin
– Color rendering index Ra ? 80
– Color stability ≤ 6 sdcm

Lifespan

– Average life 10,000 h
– Number of on/off cycles 100,000
– Survival rate after 6,000 h ≥ 0.90
– Early failure rate at 1,000 h ≤ 5.0%

Specifications

– Max. diameter 51 mm
– Diameter 51 millimeters
– Max. total length 55 mm
– Length 55 millimeters
– Operating position arbitrary
– Mercury content 0.0 mg
– Dimmable no
– Lamp shape reflector
– Material Glass
– Protection class (IP) IP20
– Color white
